Vauxhall Signum 2003-2009 Witter Detachable Towbar
G82AQ
Towbar Features
Ball Type:
Detachable
Detachable Type:
Quantum Vertical
Bumper Cuts
:
Bumper cuts are cut on the underside of the bumper.
None visible : the cut will not be visible unless you look up at the bumper from the ground.
Visible: the cut will be visible when standing behind the vehicle.
No cut: No cutting required.
No
Bypass Required
:
Many modern vehicles require a bypass relay for the towbar electrics to work correctly.
If your vehicle requires this relay then damage can occur to the cars electrics if one isn't fitted.
Our data is collected from the tow bar and tow bar wiring manufacturers with regards to whether your vehicle needs a bypass relay.
Yes
Shipping Cost
Fitting cost
- From
- £335.00
- £375.00
- £375.00
- £70.00
Additional Cost for MOBILE FITTING SERVICE*
*Estimated fitting cost only
Help & Advice
Description
Vauxhall Signum 2003-2009 Witter Detachable Towbar
Towbar demonstration video
KIT INCLUDES:
- 1 Cross Bar
- 1 LH Sidearm
- 1 RH Sidearm
- 1 RH Spreader Plate
- 1 LH Spreader Plate
- 2 Packers
- 2 Bushes 19mm O.D, 117 Long
- 2 Bushes 19mm O.D, 133 Long
- 2 M12 x 180 x 1.75 Bolts, Nyloc Nuts and Flat Washers (25mm O.D)
- 2 M12 x 165 x 1.75 Bolts, Nyloc Nuts and Flat Washers (25mm O.D)
- 4 M12 x 35 x 1.75 Bolts, Lock Washers and Flat Washers (25mm O.D)
- 2 M12 x 100 x 1.75 High Tensile Bolts, Nyloc Nuts (Grade 10.9 – Torque Setting 139Nm)
- 1 M10 x 25 x1.5 Bolt, Nut, Lock Washer and Flat Washer (25mm O.D)
- 1 Electrical Plate
- 1 Electrical Plate Angle
- 1 Towball Neck
