Westfalia Cycle carrier
Towbar Mounted

Westfalia Portilo BC60 Folding Cycle Carrier



Price includes VAT

13 pin to 7 pin adaptor
Estimate shipping cost


Westfalia Portilo BC60 Folding Cycle Carrier

  Free Number Plate & Free Delivery U.K. Mainland


(To order Number plate advise registration Number on notes of order)

The new enhanced design of the wheel supports ensure the safe attachment of the bikes

Ideal for the use with electrics bikes (wheel base up to 1300mm)

The improved rubber coating inside the frame clamps, protects the bikes

Folds down to a very compact and easy to store product

The swivel down mechanism provides easy access to the boot of the vehicle

60kg Payload

Easily extendable to carry a 3rd bike or the cargo box or platform or ski and snowboard carrier.


Bike carrier for the tow bar (D-value: 6,7 kN min. )
  • Foldable
  • Easy mounting
  • Secure and fast mounting to the tow bar, ease of use
  • Easy readjusting of the tow bar clamping force

  • When folded up:
  • 580 x 225 x 690 mm (W/H/D)
  • When unfolded:
  • 1260 x 660 x 690 mm (W/H/D)

  • Base frame: steel, welded
  • Bail: aluminium, anodised
  • Plastic parts: PA6, 30% glassfill
  • (glass fibre reinforced plastic)

Features of Carrier

  • No assembling of parts
  • Patented clamping of tow ball using a one hand levering system
  • Failsafe clamping system
  • Leverage force for clamping to towbar: approx. 300 N
  • Time to mount the carrier to vehicle: 30 sec
  • Theft protection of bike carrier itself
  • Theft protection for each bike
  • Same key fits all locks
  • Bikes are fastened using frame claws and ratchet levers
Following accessories Available:
 Portilo bike adaptor Westfalia Portilo 3rd Bike adaptor
Westfalia Portilo Box Westfalia Portilo Box

Time to mount a bike to carrier: 1 min.
Tilting function allows easy access to the trunk, while bikes are mounted


Westfalia Folding Cycle Carrier demonstration video
View this tow bar demo.


Look for the chat box at the top to speak to a customer service representative

Live help from 8.30am to 5.00pm

Or Call

0161 886 5796

Collection Available from any of our 5 depots

Similar Products


Verified order

You get what you pay for-this is an excellent piece of kit that works well for my 2 electric bikes. The 1st time of fitting takes a little while but once you've cracked it, it is really easy. Superb service from PF Jones throughout my contact from answering questions quickly to a really efficient order and despatch

Verified order

Very good carrier i read at about

Verified order

Internet order, delivered to my door within 24hrs of placing the order. Very impressed with the service!!!

Verified order

Very good service and well packaged all my orders have arrived on time never any problems.

Verified order

I am extremely happy with the service. The quality of the communication from placing the order to being able to track the package with UPS was excellent. There is nothing more reassuring than being able to track your goods once you've parted with a lot of money. The goods were well packaged and arrived undamaged. I placed the order based on a demonstration at the Camping and Caravan show in Manchester 2014. So, once the goods arrived I fitted and tested the goods and everything was I expected. Thank you for the great service.

Verified order

Totally satisfied with the order procedure

Verified order

Friendly service and very speedy delivery

Q & A

can you tell me if this cycle carrier is ok to carry road carbon bikes thanks

Asked by becky | 06/02/2016, 11:57 | 1 answer(s)

All of our towbar mounted carrier have arms on them that clamp onto the frame to hold the bikes in place. So the only thing I suggest if you want this style carrier is to use some protective padding on the frame before you clamp onto it but we still cannot guarantee that it does not mark or damage the frame.

Answered by mike

My BMW X5 with original park sensor, if use bc 60 bike carrier and box, can park sensor still workable? Thanks

Asked by Autumn | 08/12/2015, 11:33 | 1 answer(s)

Good afternoon If you fit the dedicated wiring then the sensors will turn off when you plug the cycle carrier in to the vehicle ( if the vehicle does not have a button to turn them off ) however if you fit the universal wiring the sensors will not deactivate but will pick up the cycle carrier when reversing so the honest answer is no you cant have the sensors working when the cycle carrier is attached. Kind regards ​​

Answered by aaron

Hi What is the pin connector on the Westfalia Portilo BC60 Folding Cycle Carrier. ta

Asked by James Allen  | 14/04/2015, 15:55 | 1 answer(s)

Hello James The westfalia cycle carrier comes with the 13pin connection plug kind regards

Answered by aaron

Can you confirm that the Westfalia detachable tow bar for the Evoque (323102) will be able to hold the Westfalia cycle carrier with 2 electric bikes. The 2 bikes total 46 kg. and with the 17.5 kg cycle carrier that makes 63.5 kg total. The data sheet state that the tow bar can take a vertical load of 100kg so it should be ok but a local fitter tells me that he has been told the the detachable tow bar can only take 60kg.

Asked by Graham Flack | 29/05/2014, 18:58 | 1 answer(s)

Hi Graham, I've just double checked with Westfalia and the vertical load limit for the 323102 Evoque towbar is 100Kg. Thanks.

Answered by Adam

Hello, I´d like to ask how it is with delivery service to Slovak republic, country is not on you list. I´d like to order cycle carrer system from Westfalia is it possible to deliver and what are shipping cost? thx rado

Asked by rado | 29/04/2014, 19:47 | 1 answer(s)

Hello Rado, Wecan get a Westfalia cycle carrier to you. This would be £40 by road or £88 by air . thank you.

Answered by phil

Can you tell me how much the bike carrier weighs? just trying to work out if I could fit 3 bikes onto my towbar, weight wise. thanks.

Asked by Fiona Bell | 25/04/2014, 10:26 | 1 answer(s)

Hi Fiona The 350030600001 weighs 17.5KG unloaded and can carry 60kg here is a link for any technical information kind regards ​

Answered by aaron

I have a Adria Van Conversion Motor-Home with a tow bar fitted.With the bikes on the rack would it be possible to open the back doors with the bikes and rack still fitted to the tow ball. Thank You

Asked by Martyn Hale | 26/03/2014, 16:29 | 1 answer(s)

Hi Martyn, the Westfalia cycle carrier is usually ok to open most tailgates on vehicles but for twin rear doors I'm afraid there's no definitive answer i can give you. Thanks.

Answered by Adam
