Westfalia Cycle carrier

Technical Specifications

Brand:
Westfalia
Carrier Type:
Towbar Mounted
Foldable:
Yes
How Many Cycles:
2
Tiltable:
Yes

Westfalia Portilo BC60 Folding Cycle Carrier

350030600001
13 pin to 7 pin adaptor
10 days
+
Estimate shipping cost

Westfalia Portilo BC60 Folding Cycle Carrier

  Free Number Plate & Free Delivery U.K. Mainland



(To order Number plate advise registration Number on notes of order)

The new enhanced design of the wheel supports ensure the safe attachment of the bikes

Ideal for the use with electrics bikes (wheel base up to 1300mm)

The improved rubber coating inside the frame clamps, protects the bikes

Folds down to a very compact and easy to store product

The swivel down mechanism provides easy access to the boot of the vehicle

60kg Payload

Easily extendable to carry a 3rd bike or the cargo box or platform or ski and snowboard carrier.



Bike carrier for the tow bar (D-value: 6,7 kN min. )
  • Foldable
  • Easy mounting
  • Secure and fast mounting to the tow bar, ease of use
  • Easy readjusting of the tow bar clamping force

Dimensions:
  • When folded up:
  • 580 x 225 x 690 mm (W/H/D)
  • When unfolded:
  • 1260 x 660 x 690 mm (W/H/D)

Material:
  • Base frame: steel, welded
  • Bail: aluminium, anodised
  • Plastic parts: PA6, 30% glassfill
  • (glass fibre reinforced plastic)


Features of Carrier

  • No assembling of parts
  • Patented clamping of tow ball using a one hand levering system
  • Failsafe clamping system
  • Leverage force for clamping to towbar: approx. 300 N
  • Time to mount the carrier to vehicle: 30 sec
  • Theft protection of bike carrier itself
  • Theft protection for each bike
  • Same key fits all locks
  • Bikes are fastened using frame claws and ratchet levers
Following accessories Available:
 Portilo bike adaptor Westfalia Portilo 3rd Bike adaptor
Westfalia Portilo Box Westfalia Portilo Box

Time to mount a bike to carrier: 1 min.
Tilting function allows easy access to the trunk, while bikes are mounted



Westfalia Folding Cycle Carrier demonstration video
View this tow bar demo.



Call

0161 872 4755

Collection Available from any of our 5 depots

Very easy to set up and does what its supposed to with ease
Ordered by telephone, delivered next day. Very good piece of kit, extremely robust and straightforward to fit.
I forgot to mention free number plate when I placed the order but one phone call and the plate was delivered the following day with no additional shipping cost. Excellent service throughout the order , delivery and after sales service
Excellent piece of kit. Not tried bikes on it yet (one electric) but with a payload of 60 kg I can't foresee any problems. Instructions for fitting number plate into holder could be clearer.
You get what you pay for-this is an excellent piece of kit that works well for my 2 electric bikes. The 1st time of fitting takes a little while but once you've cracked it, it is really easy. Superb service from PF Jones throughout my contact from answering questions quickly to a really efficient order and despatch
Very good carrier i read at http://fahrradtraeger-test.org/westfalia-bc-60-fahrradtr%C3%A4ger-ahk-test/ about
Internet order, delivered to my door within 24hrs of placing the order. Very impressed with the service!!!
Very good service and well packaged all my orders have arrived on time never any problems.
I am extremely happy with the service. The quality of the communication from placing the order to being able to track the package with UPS was excellent. There is nothing more reassuring than being able to track your goods once you've parted with a lot of money. The goods were well packaged and arrived undamaged. I placed the order based on a demonstration at the Camping and Caravan show in Manchester 2014. So, once the goods arrived I fitted and tested the goods and everything was I expected. Thank you for the great service.
Totally satisfied with the order procedure
Friendly service and very speedy delivery
Write a review

Hi What is the pin connector on the Westfalia Portilo BC60 Folding Cycle Carrier. ta

Asked by James Allen  | 14/04/2015, 15:55 | 1 answer(s)

Can you confirm that the Westfalia detachable tow bar for the Evoque (323102) will be able to hold the Westfalia cycle carrier with 2 electric bikes. The 2 bikes total 46 kg. and with the 17.5 kg cycle carrier that makes 63.5 kg total. The data sheet state that the tow bar can take a vertical load of 100kg so it should be ok but a local fitter tells me that he has been told the the detachable tow bar can only take 60kg.

Asked by Graham Flack | 29/05/2014, 18:58 | 1 answer(s)

Hello, I´d like to ask how it is with delivery service to Slovak republic, country is not on you list. I´d like to order cycle carrer system from Westfalia is it possible to deliver and what are shipping cost? thx rado

Asked by rado | 29/04/2014, 19:47 | 1 answer(s)

Can you tell me how much the bike carrier weighs? just trying to work out if I could fit 3 bikes onto my towbar, weight wise. thanks.

Asked by Fiona Bell | 25/04/2014, 10:26 | 1 answer(s)

I have a Adria Van Conversion Motor-Home with a tow bar fitted.With the bikes on the rack would it be possible to open the back doors with the bikes and rack still fitted to the tow ball. Thank You

Asked by Martyn Hale | 26/03/2014, 16:29 | 1 answer(s)
